Nomex® Filter Bags for the Zinc Oxide Industry: High-Temperature & Chemical-Resistant Dust Filtration Solutions

Engineering filtration stability for fine oxide fume, thermal cycling, and variable chemistry

Zinc oxide (ZnO) production creates one of the more demanding dust filtration environments in non-ferrous metallurgy. The dust is ultra-fine, thermally generated, chemically active, and produced under fluctuating operating conditions. In this context, Nomex® (aramid) filter bags are not chosen for convenience—they are chosen because they sit at a critical balance point between temperature resistance, mechanical stability, and chemical tolerance.

This article explains where Nomex filter bags fit in zinc oxide filtration, why they work when properly applied, and where their limits must be respected.

Why Zinc Oxide Dust Is Difficult to Filter

Zinc oxide dust is fundamentally different from coarse mineral dust.

Key characteristics include:

• Very fine particle size, often sub-micron to a few microns
• Low bulk density, easily re-entrained
• High process temperature, especially in indirect and direct oxidation routes
• Metal oxide chemistry, often accompanied by chlorides, sulfur compounds, or other volatiles
• Strong tendency to penetrate depth media

These properties mean that filtration failure is rarely caused by abrasion. It is caused by penetration, unstable pressure drop, and material degradation under heat and chemistry.

Where Nomex® Fits in Zinc Oxide Filtration

Nomex (aramid) fiber occupies a mid-to-high temperature performance zone that is particularly relevant to zinc oxide processes.

Typical reasons Nomex is selected include:

• Continuous operating temperatures commonly in the 180–220 °C range
• Frequent temperature spikes during load changes
• Requirement for good mechanical strength under pulse-jet cleaning
• Moderate chemical exposure that exceeds polyester capability

Nomex provides thermal headroom and mechanical resilience without moving into brittle high-temperature media like fiberglass.

Temperature Stability Under Cycling Is the Real Advantage

In zinc oxide plants, temperature is rarely steady.

Startups, shutdowns, and feed changes create:

• Rapid exhaust temperature swings
• Short-term peaks above normal operating levels
• Uneven temperature distribution across compartments

Nomex retains tensile strength and dimensional stability under these conditions better than polyester, which softens and ages quickly when pushed near its limits.

This makes Nomex especially suitable for pulse-jet baghouses exposed to repeated thermal cycling.

Chemical Resistance in Zinc Oxide Environments

Zinc oxide off-gas streams may contain:

• Metal oxides
• Chlorides
• Sulfur-bearing compounds
• Trace acidic components

Nomex offers:

• Better resistance to alkaline conditions than polyester
• Moderate tolerance to many process chemicals
• Improved durability where polyester hydrolyzes or weakens

However, Nomex is not chemically inert. Strong acids or aggressive oxidizing environments can still shorten life, which is why process chemistry must be understood—not assumed.

Fine Dust Control: Nomex Alone vs Nomex Composites

Nomex needle felt alone provides structural durability, but zinc oxide dust challenges filtration at the particle level.

Common engineering approaches include:

• Nomex needle felt where dust loading is moderate and cleaning is well controlled
• Nomex + PTFE membrane where ultra-fine ZnO fume dominates and emission stability is critical

The membrane shifts filtration to the surface, preventing deep penetration that otherwise leads to rapid DP rise and irreversible loading.

In zinc oxide service, many “Nomex failures” are actually depth-loading failures, not heat failures.

Cleaning Strategy: Where Nomex Performs Well—and Where It Does Not

Nomex tolerates pulse-jet cleaning better than more brittle high-temperature media, but it still requires discipline.

Best practices include:

• Moderate pulse pressure
• DP-based (on-demand) cleaning
• Allowing a thin, stable dust cake to remain

Over-cleaning causes:

• Accelerated fiber fatigue
• Increased penetration of fine ZnO particles
• Faster pressure drop instability

Nomex performs best when cleaning removes excess cake, not when it tries to expose bare fabric.

Moisture and Condensation: A Hidden Risk

Although zinc oxide processes are hot, condensation risk often appears:

• During startups and shutdowns
• In downstream ducting
• With cold air in-leakage

Moisture combined with metal oxide dust can:

• Harden cake layers
• Reduce cleaning effectiveness
• Accelerate chemical interaction with fibers

Maintaining adequate dew point margin is essential for achieving predictable Nomex bag life.

Typical Zinc Oxide Applications Using Nomex Filter Bags

Nomex filter bags are commonly applied in:

• Zinc oxide fume collection from oxidation furnaces
• Baghouse systems downstream of cyclones
• Secondary dust collection in ZnO handling and packaging
• Processes requiring higher temperature tolerance than polyester

In these roles, Nomex acts as a reliable thermal and mechanical backbone for stable filtration.

Where Nomex Is Often Misapplied in ZnO Plants

Nomex may underperform when:

• Ultra-fine dust dominates but no membrane is used
• Strong acidic or oxidizing gases are present
• Condensation events are frequent
• Aggressive pulsing is used to fight penetration-driven DP rise

In such cases, upgrading structure (membrane, surface treatment) or changing base media may be required.

A Practical Engineering Takeaway

In the zinc oxide industry, Nomex filter bags are valued not simply for “high temperature resistance,” but for their ability to survive thermal cycling and mechanical stress while maintaining filtration stability.

They deliver best results when:

• Temperature exceeds polyester limits but remains below extreme high-temperature regimes
• Dust is fine but managed through surface filtration strategies
• Cleaning is controlled rather than aggressive
• Moisture and chemistry are actively managed

When applied within this operating window, Nomex filter bags provide stable pressure drop, predictable service life, and reliable emission control in zinc oxide dust collection systems.

Omela Filtrations supports zinc oxide producers by aligning dust characteristics, temperature profiles, chemical exposure, and filter bag construction, ensuring Nomex-based filtration solutions perform reliably across the full production cycle—not just under ideal conditions.

---
