Q: What is FMS Needle-Punched Felt and where is it typically used?

FMS Needle-Punched Felt is a high-temperature composite fiber filter media , combining fiberglass, aramid, and other heat-resistant fibers. It is designed for extremely harsh flue-gas environments with high temperature, corrosive chemicals, and abrasive dust . Common applications include: Metallurgical furnaces & smelting operations Blast-furnace gas systems Cement kilns & clinker lines Waste-to-energy (WtE) plants Coal/biomass boilers High-temperature industrial gas filtration

Q: What is the operating temperature range for FMS Needle-Punched Felt?

FMS felt delivers reliable thermal performance with: Continuous temperature: 240–260 °C Peak/instant temperature: 280–300 °C This makes it suitable for the most demanding high-temperature dust-collection systems.

Q: How does FMS compare to fiberglass or aramid felts?

FMS combines the strengths of multiple fibers: Higher chemical resistance than aramid Lower shrinkage & better dimensional stability than organic felts Better abrasion resistance and longer bag life than standard fiberglass FMS is preferred when the environment is simultaneously hot, abrasive, and chemically aggressive .

Q: What factors should be evaluated before selecting FMS filter bags?

Omela recommends assessing: Continuous and peak temperature Frequency of thermal cycling Acid dew point & condensate risk Chemical components (SOₓ, NOₓ, chlorides, alkalis, sulfates) Dust loading & abrasiveness Air-to-cloth ratio and desired filtration performance Compatibility with cage design and cleaning system parameters Proper evaluation ensures maximum service life and efficiency.

Q: Can FMS Needle-Punched Felt be customized?

Yes. Omela offers full customization, including: Felt weight, thickness, fiber blend, permeability Scrim reinforcement or multi-layer composites PTFE impregnation , PTFE membrane, singed or calendared finishes Custom bag construction (top/bottom designs, sewn/welded seams) Engineering support for integration with existing or new baghouse systems

Q: What quality tests are performed on FMS Needle-Punched Felt?

Each batch undergoes strict testing, including: Air permeability & pressure-drop verification Tensile strength & elongation tests Heat-shrinkage & dimensional stability at 260–300 °C Chemical resistance checks Microscopic fiber & surface inspection Verification of PTFE impregnation or membrane integrity Abrasion-resistance evaluation

FMS Needle-Punched Felt

FMS Needle-Punched Felt Overview

FMS Needle-Punched Felt is a high-temperature composite-fiber filtration material engineered for extremely hot, chemically aggressive, and high-stress industrial flue-gas environments. By combining fiberglass, aramid (or other high-temperature fibers), and optional PTFE-based surface treatments, FMS provides outstanding resistance to heat, acids/alkalis, corrosion, abrasion, and long-term mechanical fatigue. It is designed to perform reliably under heavy dust loads and harsh operating conditions.

Where FMS Performs Best

Blast-furnace gas and metallurgical smelting
Cement kilns and high-temperature clinker/calcining processes
Waste-to-energy incineration systems
Coal-fired and biomass power plant boilers
High-temperature, dust-laden industrial gas streams

Key Selection Criteria

Temperature profile: continuous and peak (240–260 °C continuous, 280–300 °C peaks)
Chemical composition: acid/alkali levels, chlorides, sulfates
Dust characteristics: abrasiveness, hardness, particle size distribution
Filtration load: air-to-cloth ratio, filtration velocity
Cleaning system parameters: pulse-jet intensity, frequency
Baghouse design compatibility and mechanical stress conditions

Key Performance Benefits

Exceptional High-Temperature Resistance

Withstands continuous 240–260 °C operation and 280–300 °C peak temperatures without shrinkage, brittleness, or structural degradation.

Outstanding Chemical Stability

Resistant to acids, alkalis, chlorides, sulfates, and corrosive flue-gas components—ideal for cement kilns, metallurgy, WtE, and high-temperature industrial gas streams.

Enhanced Abrasion & Wear Resistance

Composite fiber structure (fiberglass + aramid) offers superior durability against high-velocity dust, abrasive particles, and mechanical fatigue, extending bag life in harsh systems.

Compatible with Advanced Surface Treatments

Can be upgraded with PTFE impregnation, PTFE membrane, singeing, or calendaring to improve dust release, chemical resistance, and long-term filtration stability.

Engineered for Extreme Industrial Conditions

Perfect for metallurgical smelting, blast-furnace gas, cement clinker lines, waste-to-energy incinerators, and other systems with intense heat, corrosive chemistry, and heavy dust loading.

Flexible Supply & Customization Options

Available as roll goods or as custom-fabricated filter bags tailored to application-specific requirements such as temperature, chemistry, and mechanical stress.

FMS Needle-Punched Felt Specifications

Technical Properties of FMS Needle-Punched Felt
Fiber	Mixed fiber
Scrim	Fiberglass yarn
Weight (g/m²)	850
Thickness (mm)	2.4
Width (m)	≤2.2
Finish Treatment	PTFE impregnation
Air Permeability (L/m²·s @200Pa)	200–300
Tensile Strength (N/5×20cm)	Warp: 1300
Tensile Strength (N/5×20cm)	Weft: 1500
Tensile Elongation (%)	Warp: 8
Tensile Elongation (%)	Weft: 8
Temperature
Continuous Temperature (°C)	240
Instant Temperature (°C)	280
Chemical Properties
Anti-acid	Good
Anti-alkali	Good
Anti-abrasion	Good
Hydrolysis Stability	Middle

Download Catalog (PDF)

INDUSTRIAL
APPLICATIONS

FMS Needle-Punched Felt is engineered for extreme-temperature, chemically aggressive, and abrasive industrial environments. This makes FMS the ideal choice for industries such as metallurgy, cement production, waste-to-energy, mining, and high-temperature combustion processes.

More Applications

Cement, Lime & Mineral Processing

Idea for Exhaust gas temperatures are extremely high , Dust is highly abrasive, Chemical components (SO₂/SO₃, alkalis) accelerate filter degradation, FMS felt maintains excellent thermal stability and long bag life under these harsh conditions.

Metallurgical Furnaces & Smelting Operations

FMS withstands extreme temperature peaks, mechanical stress, and chemically aggressive gas streams typical of metallurgical environments.

Waste-to-Energy (WtE) & High-Temperature Combustion

FMS provides high resistance to acid dew point corrosion, condensate attack, and SOx/Cl-based corrosive gases, ensuring lower emissions and extended service life.

Engineering Support & Customization

Pre-Project Technical Evaluation

Operating temperature window
(continuous 240–260 °C, peak 280–300 °C depending on system conditions)
Thermal cycling frequency and start-up / shut-down behavior
Moisture level, acid dew point, and risk of condensate corrosion
Chemical composition of the gas stream
(acids, alkalis, chlorides, sulfates, SOₓ, NOₓ)
Dust loading, abrasiveness, particle size distribution
Required filtration efficiency, air-to-cloth ratio, and allowable pressure drop
Compatibility with existing bag cages, tube-sheet layout, and cleaning system parameters

Custom Engineering Solutions

Selection of felt weight, thickness, fiber blend, and permeability
Optional scrim reinforcement or multi-layer composite structures for higher mechanical strength
Customized surface treatments:
PTFE impregnation, PTFE membrane, singed or calendared finishes for improved dust release and chemical resistance
Optimization for:
metallurgical furnaces, blast-furnace gas, cement kilns, waste-to-energy systems, high-temperature and corrosive process gas
Custom filter-bag construction:
top/bottom designs, sewn or welded seams, reinforcement of high-stress zones
Engineering support to ensure proper fit, mechanical stability, and performance in new or existing baghouse systems

Quality Assurance & Testing

Air permeability and pressure-drop verification at specified differential pressure
Tensile strength and elongation testing in both machine and cross directions
Heat-shrinkage and dimensional stability tests at high operating temperatures (up to 260–300 °C)
Chemical-resistance testing in relevant acidic and alkaline media
Microscopic inspection of fiber distribution, needling density, bonding quality, and surface finish
Verification of PTFE impregnation or membrane coating integrity, adhesion, and uniformity
Abrasion-resistance evaluation to ensure durability under heavy-dust conditions
