Acrylic Membrane Filter Bags For Cement & Steel Plant

Acrylic Membrane Filter Bags for Cement & Steel Plants

Managing acidic gas, moderate heat, and fine dust with stable surface filtration

In cement and steel plants, not every filtration zone operates at extreme temperature. Many critical dust collection points sit in a moderate-temperature but chemically challenging window, where acidic gases, fine particulate, and moisture risk dominate failure mechanisms. In these environments, acrylic membrane filter bags offer a practical and often underutilized solution.

Their value lies not in pushing thermal limits, but in maintaining stable filtration behavior where chemistry and condensation risk undermine conventional polyester media.

Why Acrylic Media Matters in Cement & Steel Applications

Acrylic fiber (PAN-based) occupies a distinct position among industrial filter media:

• Better resistance to acidic gases than polyester
• More stable under humid and condensation-prone conditions
• Adequate temperature capability for many downstream and auxiliary zones
• Compatible with pulse-jet cleaning in compact baghouses

When combined with a PTFE membrane, acrylic filter bags shift from depth filtration to controlled surface filtration, directly addressing fine dust penetration and pressure-drop instability.

Typical Operating Conditions Where Acrylic Is Effective

Acrylic membrane filter bags perform best in zones characterized by:

• Continuous temperatures typically below 120–130 °C
• Presence of acidic components (SO₂, HCl, acidic condensates)
• Fine dust with penetration tendency
• Intermittent moisture or high ambient humidity
• Pulse-jet baghouses requiring stable cleaning response

These conditions are common in cement grinding, clinker handling auxiliaries, steel secondary dust collection, and downstream gas-cleaning stages.

Cement Plant Applications: Where Acrylic Makes Sense

In cement plants, acrylic membrane filter bags are often applied in:

• Finish grinding and cement milling
  Fine powder, moderate temperature, tight emission limits
• Cement packing and bulk loading
  Stable airflow required; dust is extremely fine and mobile
• Auxiliary dedusting systems
  Areas exposed to ambient humidity and acidic traces from additives

In these zones, polyester often fails prematurely due to acid hydrolysis and moisture sensitivity, while higher-temperature media add cost without extending life.

Steel Plant Applications: Chemical Stability Over Heat Rating

Steel plants include many dust sources that are not furnace-hot, but are chemically aggressive:

• Secondary dedusting around material handling
• Pickling line exhaust and downstream dust capture
• Sinter and pellet auxiliary systems (cooler sections)
• Fume treatment downstream of cooling and conditioning

Here, acidic gases and moisture—rather than heat—drive media degradation. Acrylic membrane filter bags resist these conditions more reliably than standard polyester.

The Role of the PTFE Membrane on Acrylic Felt

The PTFE membrane fundamentally changes acrylic bag behavior:

• Captures fine particles at the surface
• Prevents deep penetration and internal blinding
• Stabilizes differential pressure early
• Improves cleaning efficiency with lower pulse energy

Without a membrane, acrylic felt may still load internally in fine dust applications. With a membrane, it becomes a low-resistance, emission-stable solution for moderate-temperature zones.

Cleaning Behavior and Operational Stability

Acrylic membrane filter bags perform well in pulse-jet systems when cleaning is controlled.

Best practices include:

• Moderate pulse pressure
• DP-based cleaning rather than fixed intervals
• Allowing a thin, stable dust cake to remain

Over-cleaning accelerates mechanical fatigue and membrane wear—this is a system issue, not a material limitation.

Moisture and Condensation Resistance

Compared with polyester, acrylic offers:

• Improved resistance to acidic moisture attack
• Better recovery after short condensation events
• Reduced risk of irreversible hydrolysis

That said, acrylic is not immune to repeated wet operation. Dew point control remains essential, but acrylic provides a wider safety margin in humid environments.

Comparison with Common Alternatives

Media Type	Acid Resistance	Temp Capability	Moisture Tolerance	Typical Limitation
Polyester	Poor–Moderate	Moderate	Poor	Hydrolysis in acidic moisture
Acrylic + PTFE	Good	Moderate	Good	Not for high heat
PPS	Moderate	Medium–High	Moderate	Oxidation risk
Aramid	Moderate	High	Moderate	Acid sensitivity
PTFE Felt	Excellent	Very High	Excellent	Higher cost

This highlights why acrylic membrane bags are a targeted solution, not a universal replacement.

Common Misapplications to Avoid

• Using acrylic in high-temperature kiln or furnace exhaust
• Applying acrylic without a membrane in ultra-fine dust zones
• Over-pulsing to fight DP instead of stabilizing cake formation
• Treating acidic condensation as a rare event

Correct application is what delivers value—not the material alone.

A Practical Engineering Takeaway

Acrylic membrane filter bags offer a balanced, cost-effective filtration solution for cement and steel plant zones where acidic gas, fine dust, and moisture risk dominate—but extreme temperature does not.

They deliver the best results when:

• Temperature remains within acrylic limits
• Chemical resistance is more critical than heat resistance
• Fine dust penetration drives DP instability
• Cleaning is controlled and conservative

When selected for the right zones, acrylic membrane filter bags provide stable emissions, predictable service life, and lower operating cost—without the over-specification often seen when temperature ratings are prioritized over real failure mechanisms.

Omela Filtrations supports cement and steel producers by aligning process chemistry, temperature reality, dust behavior, and membrane technology, ensuring acrylic membrane filter bags are applied where they truly solve problems—rather than where they simply appear adequate on paper.

---
